The Tungsten Carbide Nozzle is a unique and highly versatile component known for its exceptional durability, wear resistance, and precision in various industrial applications. Designed for precise fluid or gas control, the Tungsten Carbide Nozzle offers outstanding performance, reliability, and longevity, making it an indispensable tool in a wide range of industries.
Features of tungsten carbide nozzles:
1. Select high-quality tungsten carbide material to manufacture tungsten carbide nozzle
2. Sintered with HIP technology, tungsten carbide nozzle has high hardness and wear resistance
3. Wide selection of sizes, specifications and material grades
4. Reasonable price, strong supply capacity and fast delivery time
5. OEM customization, providing optimal solutions, professional technical support
Applications:
Precision Cutting: Tungsten carbide nozzles excel in precision cutting applications where intricate shapes and clean edges are critical.
Mining and Quarrying: Tungsten carbide nozzles play a vital role in mining and quarrying operations, especially during abrasive rock drilling and cutting.
Steel Manufacturing: In the steel industry, tungsten carbide nozzles are critical for precision steel cutting and cooling processes.
Automotive industry: Tungsten carbide nozzles are used in precision machining such as high-pressure coolant delivery during turning, milling or grinding operations, ensuring effective heat dissipation and extending tool life.
Wastewater treatment: Tungsten carbide nozzles are suitable for processes such as aeration and mixing in wastewater treatment plants.
Oil and Gas Industry: Tungsten carbide nozzles play a vital role in applications such as drilling mud injection, hydraulic fracturing and well stimulation
Langsun Carbide continuously supplies long life and reliable quality tungsten carbide nozzles. Available in a variety of sizes, specifications and material grades. Langsun Carbide can manufacture various types of tungsten carbide nozzles, including sandblasting nozzles, fuel injection nozzles, air nozzles and various non-standard tungsten carbide nozzles, etc.
| Tungsten carbide material specification | |||||
| Grade | Binder (Wt %)Cobalt | Density (g/cm3) | Hardness (HRA) | TRS (>N/mm²) | Grain Size(μm) |
| YG6 | 5.8-6.3 | 14.6-15.0 | 89.5-91 | 1800 | 0.8-2.0 |
| YG6X | 5.8-6.3 | 14.4-14.7 | 90.5-91.5 | 1650 | 0.6-1.0 |
| YG8 | 7.5-8.2 | 14.4-14.7 | 89.0-90.5 | 2200 | 1.0-1.5 |
| YG11 | 11.0-11.5 | 14.2-14.4 | 87.0-88.5 | 2800 | 1.0-2.0 |
| YG11C | 11.0-11.5 | 14.2-14.4 | 86.0-88.0 | 3000 | 1.0-2.5 |
| YG15 | 14.5-15 | 13.9-14.0 | 86.0-88.0 | 3300 | 1.0-2.0 |
| YG20 | 20.0-20.5 | 13.2-13.5 | 84.0-85.0 | 3400 | 1.0-2.0 |
| YG20C | 20.0-20.5 | 13.2-13.5 | 83.0-85.0 | 3600 | 1.0-2.5 |
| K05VF | 4.5-5.0 | 14.6-15.0 | 92.5-93.0 | 1500 | 0.6-1.0 |
| K10VF | 5.5-6.2 | 14.5-14.7 | 91.5-92.5 | 1550 | 0.6-1.0 |
| K20VF | 7.5-8.0 | 14.5-14.7 | 90.5-91.5 | 1800 | 0.6-1.0 |
| YN6 | 5.5-6.2 | 14.6-15.0 | 89.5-90.5 | 1800 | 0.8-2.0 |
| YN6X | 5.9-6.5 | 14.5-14.9 | 89.4-91 | 1750 | 0.8-1.8 |
| YN6A | 5.9-6.5 | 14.5-14.8 | 89.5-91.5 | 1850 | 0.8-1.8 |
| YN7 | 6.8-7.2 | 14.4-14.8 | 89.0-90.0 | 1900 | 0.8-1.6 |
| YN8 | 7.8-8.3 | 14.5-14.8 | 89.0-90.0 | 2200 | 0.8-2.0 |
| YN12 | 11.5-12.2 | 14.0-14.4 | 87.5-88.5 | 2600 | 0.8-2.0 |
| YN15 | 14.5-15.2 | 13.7-14.2 | 86.5-88.0 | 2800 | 0.6-1.5 |
