The nozzle of Tungsten carbide 3D printer needs high-level processing technology. We must pay attention to the roughness of the inner hole wall. Our company can adjust the accuracy of the equipment according to the product requirements for batch production, while ensuring that the thread end surface ensures a certain level of accuracy. Unlike our competitiors, our products are pure Tungsten carbide and contain no other materials. We achieve long-term stable printing by printing conventional PLA to PEEK and then to carbon fiber reinforced materials.
Grade | Binder (Wt %)Cobalt | Density (g/cm3) | Hardness (HRA) | TRS (>N/mm²) | Grain Size(μm) |
YG6 | 5.8-6.3 | 14.6-15.0 | 89.5-91 | 1800 | 0.8-2.0 |
YG6X | 5.8-6.3 | 14.4-14.7 | 90.5-91.5 | 1650 | 0.6-1.0 |
YG8 | 7.5-8.2 | 14.4-14.7 | 89.0-90.5 | 2200 | 1.0-1.5 |
YG11 | 11.0-11.5 | 14.2-14.4 | 87.0-88.5 | 2800 | 1.0-2.0 |
YG11C | 11.0-11.5 | 14.2-14.4 | 86.0-88.0 | 3000 | 1.0-2.5 |
YG15 | 14.5-15 | 13.9-14.0 | 86.0-88.0 | 3300 | 1.0-2.0 |
YG20 | 20.0-20.5 | 13.2-13.5 | 84.0-85.0 | 3400 | 1.0-2.0 |
YG20C | 20.0-20.5 | 13.2-13.5 | 83.0-85.0 | 3600 | 1.0-2.5 |
K05VF | 4.5-5.0 | 14.6-15.0 | 92.5-93.0 | 1500 | 0.6-1.0 |
K10VF | 5.5-6.2 | 14.5-14.7 | 91.5-92.5 | 1550 | 0.6-1.0 |
K20VF | 7.5-8.0 | 14.5-14.7 | 90.5-91.5 | 1800 | 0.6-1.0 |
Carbide Nozzle is widely used in all fields requiring 3D printers and is an important part of FDM (melt deposition molding) 3D printers
Highlights:
1. Precision grinding and high polishing process
2. High wear resistance, high pressure resistance and thermal stability,
3. Top experts continue to refine product performance.
Pre-sales and after-sales service：
Because our company has a variety of products and a high level of technology, we can meet any customer's demand for Tungsten Carbide Nozzles. If the products are damaged within a certain period of time after purchase, contact us at the first time and we will make corresponding remedial measures.
Application industries:
medical industry, aerospace, automobile industry, food and beverage, etc
