Precision Tolerance Tungsten Carbide Blasting Nozzle is a high-performance sand blasting tool for various sand blasting processing scenarios. It has precise tolerance control capability, good blasting effect and long service life, which can improve working efficiency, processing quality and reduce cost.
This sandblasting nozzles are precision engineered for extremely high tolerance control. Tolerance control refers to the degree of control of product size, shape, position and other elements during the manufacturing process. High-precision tolerance control ensures that the sandblasting nozzle fits accurately with other equipment, improving work efficiency and processing quality.
Excellent characteristics of tungsten carbide nozzle:
1. High precision tolerance.
2. Stable spraying capability.
3. High melting point and thermal stability.
4. Resistant to acids and alkalis.
Cobalt Binder Grades
| Grade | Binder (Wt %) | Density (g/cm3) | Hardness (HRA) | TRS (≥N/mm²) |
| YG6 | 6 | 14.8 | 90.0 | 1520 |
| YG6X | 6 | 14.9 | 91.0 | 1450 |
| YG6A | 6 | 14.9 | 92.0 | 1540 |
| YG8 | 8 | 14.7 | 89.5 | 1750 |
| YG12 | 12 | 14.2 | 88.0 | 1810 |
| YG15 | 15 | 14.0 | 87.0 | 2050 |
| YG20 | 20 | 13.5 | 85.5 | 2450 |
| YG25 | 25 | 12.1 | 84.0 | 2550 |
Nickel Binder Grades
Grade | Binder (Wt %) | Density (g/cm3) | Hardness (HRA) | TRS (≥N/mm²) |
YN6 | 6 | 14.7 | 89.5 | 1460 |
YN6X | 6 | 14.8 | 90.5 | 1400 |
YN6A | 6 | 14.8 | 91.0 | 1480 |
YN8 | 8 | 14.6 | 88.5 | 1710 |
