Venturi Nozzles

  • brand_name OEM/LANGSUN
  • place_of_origin China
  • minimun_order_quantity 10
  • supply_ability 10000 PCS/MONTH
  • payment_terms L/C,T/T,Western Union
  • certficate ISO9001

The working principle of tungsten carbide venturi nozzle is to realize the spraying effect through the shear force and impact force generated by the high-speed flow of fluid. Its design structure makes the fluid form a high-speed vortex inside the nozzle, thus dispersing the fluid into fine particles and realizing fine spraying. At the same time, the high hardness and wear resistance of tungsten carbide material can ensure the long-term stable operation of the nozzle.

Tungsten carbide venturi nozzle is widely used in various industrial fields, such as petrochemical, metallurgy, aerospace, electronics and so on. It can be used for spraying, cleaning, cooling, atomizing and many other processes, with the advantages of fast spraying speed, good spraying effect and long service life.


Langsun Carbide can provide customers with tungsten carbide nozzles of any shapes, sizes and types. With decades of experience in manufacturing tungsten carbide nozzles, we have absolute confidence in providing customers with tungsten carbide nozzles of top quality.


Cobalt Binder Grades

Grade

Binder (Wt %)

Density (g/cm3)

Hardness (HRA)

TRS (>N/mm²)

YG6

6

14.8

90.0

1520

YG6X

6

14.9

91.0

1450

YG6A

6

14.9

92.0

1540

YG8

8

14.7

89.5

1750

YG12

12

14.2

88.0

1810

YG15

15

14.0

87.0

2050

YG20

20

13.5

85.5

2450

YG25

25

12.1

84.0

2550


 Nickel Binder Grades

Grade

Binder (Wt %)

Density (g/cm3)

Hardness (HRA)

TRS (>N/mm²)

YN6

6

14.7

89.5

1460

YN6X

6

14.8

90.5

1400

YN6A

6

14.8

91.0

1480

YN8

8

14.6

88.5

1710
